Specification
●Length: 1218mm
●Height: 353mm
●Width: 183mm
●Main Blade Length: 600mm
●Main Rotor Diameter: 1339mm
●Tail Length: 95mm
●Tail Rotor Diameter: 253mm
●Motor Belt Pulley: 23T
●Belt Pulley: 44T
●Front Drive Main Shaft: 15T
●Main Drive Gear: 62T
●Autorotation Tail Drive Gear: 28T
●Tail Drive Gear: 23T
●Drive Gear Ratio: 7.89:1:5.04
●Max RPM(approx.): 2300RPM
●Weight(w/o Batteies): Approx. 2.8kg
Accessories
●TB60 Kit Set x 1 set
●600 Carbon Fiber Blades x 1 set
●95 Carbon Fiber Tail Blades x 1 set
●750MX Brushless Motor(930KV/4236) x 1
●DS830M High Voltage Brushless Servo x 3
●DS835M High Voltage Brushless Servo x 1
●RCE-BL150A Brushless ESC x 1
●MICROBEAST² Flybarless System x 1
●Lube Pack x 1
Radio transmitter and electronic equipment required for assembly
●Transmitter(6-channel or more, helicopter system)
●Receiver(6-channel or more) or Remoet Receiver
●RCC-6CX Intelligent Balance Charger
●6S Li-Po 2600 ~ 4600mAh x 2 (3300mAh suggestion)
●Digital Pitch Gauge
●Multi-function Tester
|
